High-Contrast ABS Double color Laser Engraving Sheets for Durable Industrial Signage
ABS Laser-Cutting Sheets - Product Specifications
Produktübersicht
ABS Laser-Cutting Sheets are engineered thermoplastic panels optimized for precision laser cutting and engraving. Ideal for prototyping, industrial design, and custom fabrication, they deliver clean edges, minimal warping, and consistent results with CO₂ or fiber lasers.
Hauptmerkmale
✔
High Laser Compatibility
Compatible with CO₂ (40-120W) & diode lasers.
Minimal melting/residue for sharp edges.
✔ Superior Material Properties
Impact resistance & lightweight (1.02-1.06 g/cm³ density).
Heat deflection temp: 90-105°C.
Optional flame-retardant additives available.
✔ User-Friendly Design
Pre-treated anti-static surfaces (reduces dust adhesion).
Matte/gloss finish options for aesthetics.
Technical Parameters
| Property | Spezifikation |
|---|---|
| Thickness | 1mm / 2mm / 3mm / 5mm (±0.1mm) |
| Sheet Size | 600mm × 300mm / 1200mm×600mm |
| Farboptionen | Black, White, Red, Transparent |
| Density | 1.04 g/cm³ |
| Betriebstemperatur | -20°C to +80°C |
| Laser Speed (CO₂ 60W) | 8-15 mm/s (cutting) |
Anwendungen
◼
Rapid Prototyping
– Functional enclosures, gears, snap-fit components.
◼
Signage & Displays
– Retail lettering, LED light-diffusing panels.
◼
Education & Hobby
– Robotics parts, architectural models, DIY crafts.
◼
Automotive
– Interior trim prototypes, custom dash components.
Processing Guidelines
⚠
Laser Settings (CO₂):
Cutting: Power 70-85%, 2 passes recommended for 3mm+ thickness.
Engraving: 300-600 DPI, 60% power.
⚠ Ventilation Required – Use fume extractor to eliminate ABS fumes.
Verpackung & Ordering
Standard Pack: 10 sheets/box (600×300mm).
Custom sizes/thicknesses: MOQ 50 sheets.
Sample Packs: Available (4 colors × A5 size).
Safety Compliance
RoHS-certified.
MSDS available upon request.
